Components
INE-1KW-OFF
INE-2KW-OFF
INE-3KW-OFF
INE-4KW-OFF
INE-5KW-OFF
320W Mono Solar Panel
2 Piece
4 Piece
6 Piece
9 Piece
12 Piece
Off Grid Inverter
1KW
2KW
3KW
4KW
5KW
Combiner Box
/
/
/
3 in 1 out
4 in 1 out
12V 200AH Battery
1 Piece
2 Piece
4 Piece
4 Piece
8 Piece
PV cable
100 Meters
100 Meters
200 Meters
200 Meters
200 Meters
Battery Cable
3 Piece
4 Piece
6 Piece
6 Piece
10 Piece
MC4 Connector
4 Set
4 Set
6 Set
6 Set
8 Set
Mounting System
Metal Roof/Tile Roof/Tilt Mounting/Ground Mounting
* Above information is for reference only, specific configuration is depend on customer's requirement and in accordance with the actual order.
Rated Maximum Power: 320W (INE-320-60M)
Maximum Power Voltage: 33.46V
Maximum Power Current: 9.56A
Open Circuit Voltage: 40.97V
Short Circuit Current: 10.9A
Dimensions:1640×992×35 mm (64.5×39.1×1.38 inches)
Weight:18.5 kg (41.0 lb)
Rate power:1/2/3/4/5 KW
AC Voltage Regulation:230VAC±5%
Surge Power :6000VA/10000VA
Battery Voltage:24 VDC / 48 VDC
Maximum Charge Current:80A/60A
Maximum PV Array Power:5000w
Dimensions:100x300x440mm
Color:White/Grey
Product name:PV combiner box
Connection:2,4,6,8,10,12,14,16,20,24 Ways
Character:With monitor,thunder-proof,water-proof
Rated working current:UP TO 250A
Protection Level:IP65
BOX Material:Iron Steel
Cells Per Unit:6
Nominal Voltage(Vdc): 12
Nominal Capacity(AH): 200
Depth of Discharge: 70%
Design Life: 10-15 years
Capacity: 200Ah@10hr-rate to 1.80V per cell
@25°C
Design Standard：AS/NZS 1170,DIN 1055, JIS C
8955
Material: AL 6005-T5,SUS 304,Q235B
Fastener: SUS304
Small Components:Al6005-T5(Anodized)
Color:Silver or Customized
Warranty:10-Year Warranty
Cross Section: 4mm2, 6mm2 Optional
Rated Voltage:600VDC(UL)/1000VDC(TUV)
Rated Current: 55A,70A
Colors: Black For STD, Red Optional.
Wire Cable Cutter and Stripper,
MC3 MC4 Crimping Tools
MC4 Connectors Assembly
Disassembly Tool
