Product Type
 INE-120KW-OFF
 INE-150KW-OFF
 INE-180KW-OFF
 INE-200KW-OFF
 INE-250KW-OFF
320W Mono Solar Panel
 320 Piece
 384 Piece
 480 Piece
 576 Piece
 640 Piece
Off Grid Inverter
 120KVA
 150KW
 180KW
 200KW
 150KW
MPPT Controller
 2*360V 200A
 2*360V 200A
 4*360V 200A
 4*360V 150A
 4*360V 150A
Combiner Box
 8*4 in 1 out
 8*4 in 1 out
 12*4 in 1 out
 16*4 in 1 out
 16*4 in 1 out
12V 200AH Battery
 90 Piece
 120 Piece
 150 Piece
 240 Piece
 270 Piece
PV cable
 800 Meters
 800 Meters
 800 Meters
 1000 Meters
 1000 Meters
Battery Cable
 92 Piece
 122 Piece
 152 Piece
 242 Piece
 272 Piece
MC4 Connector
 30 Set
 30 Set
 30 Set
 50 Set
 50 Set
PV Tools
 1 Set
 1 Set
 1 Set
 1 Set
 1 Set
Mounting System
 Metal Roof/Tile Roof/Tilt Mounting/Ground Mounting

* Above information is for reference only, specific configuration is depend on customer's requirement and in accordance with the actual order.



Mono Solar Panels

Rated Maximum Power: 380W (INE-380-72M)
Maximum Power Voltage: 36.97V
Maximum Power Current: 7.79A
Open Circuit Voltage: 44.69V
Short Circuit Current: 8.26A
Dimensions:1956X992X40mm
Weight:22.5 kg

Off Grid Inverter

Rate power:40/50/60/80/100/120/150/180/200/250KW
Phase:Three phases+N+G
Rated DC voltage(VDC): 220/360
Nominal Voltage :380VAC±1%(Static load)
Inverter Efficiency:≧90%
Communication:RS232/RS485

PWM Controller (MPPT optional)

Rated Voltage (VDC):360
Rated charging current:50-200
Maximum PV open-circuit voltage:720
Input paths(maximum): 4
Protection level: IP 20
Dimension(WxHxD)mm : 440*440*660
Weight(Kg) : 32-40

PV COMBINER BOX

Color:White/Grey
Product name:PV combiner box
Connection:2,4,6,8,10,12,14,16,20,24 Ways
Character:With monitor,thunder-proof,water-proof
Rated working current:UP TO 250A
Protection Level:IP65
BOX Material:Iron Steel

Lead Acid GEL Battery

Cells Per Unit:6
Nominal Voltage(Vdc): 12
Nominal Capacity(AH): 200
Depth of Discharge: 70%
Design Life: 10-15 years
Capacity: 200Ah@10hr-rate to 1.80V per cell
@25°C

PV Mounting System

Design Standard：AS/NZS 1170,DIN 1055,
JIS C 8955
Material: AL 6005-T5,SUS 304,Q235B
Fastener: SUS304
Small Components:Al6005-T5(Anodized)
Color:Silver or Customized
Warranty:10-Year Warranty

PV Cable & MC4 Connector

Cross Section: 4mm2, 6mm2 Optional
Rated Voltage:600VDC(UL)/1000VDC(TUV)
Rated Current: 55A,70A
Colors: Black For STD, Red Optional.

PV Tools

Wire Cable Cutter and Stripper,
MC3 MC4 Crimping Tools
MC4 Connectors Assembly
Disassembly Tool
